10 Watt RGB High Power LED Diodes / 90 Degree Power LED Module
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 10W 90 Degree Power LED Module ,10 Watt RGB High Power LED Diodes | Size | 31.8*22.48*5.9mm |
|---|---|---|---|
| Viewing Angle | 90degree | Voltage | R:6-7V,G:9-11V,B:9-11V |
| Current | R:400ma,G:350ma,B:350ma | Wavelength | R:620-630nm,G:520-530nm,B:460-470nm |
| Chips | 45mil Chip | Luminous Flux | R:120-180lm,G:180-240lm,B:30-60lm |
| Thermal Resistance | 12C/W | ||
| Highlight | high power rgb led,bridgelux led chip |
||
Product Description
10W 90 degree Power LED Module ,10 watt RGB High Power LED Diodes
Quick Detail:
1. Model:SP10WRGB
2. Size: 31.8*22.48*5.9mm
2. Viewing angle: 90degree
3. Voltage:R:6-7V,G:9-11V,B:9-11V
4. Current:R:400ma,G:350ma,B:350ma
5. Wavelength : R:620-630nm,G:520-530nm,B:460-470nm
6. Chips: 45mil chip
7. Luminous Flux:R:120-180lm,G:180-240lm,B:30-60lm
8. Thermal Resistance :12C/W
Description:
Best raw materials used in our LED production :
1)Chip: Taiwan 45MIL chip;
2) Silicon glue: USA Dowcorning (good glue has less lighting decreasing);
3) Powder: USA Intermatix (good powder has better performance in lumens);
4) Gold wire: Germany Herqeus 1.0mil Gold wire(for bearing bigger current, gold wire has less electricity resistance than silver and cooper) ;
5) Led base:red/ black cooper base .
Super high Flux output and high Luminance ,Designed for high current operation,Low thermal resistance ,SMT solder technology ,Lead Free product,ROHS compliant
We have many kind of color for your choice like : Warm white , Natural white , Cool white , Red , Blue , Green , Yellow etc.
6)Free samples and 2 years warranty .
Specifications:
|
Product Name |
10W RGB Power LED Module ,10 watt RGB Led Diodes |
|
Model No |
SP10WRGB |
|
Finishing |
Reflow soldering |
|
Material |
Taiwan chip 45mil |
|
MOQ |
100pcs |
|
Size |
31.8*22.48*5.9mm |
|
Package |
10pcs/reel ,100pcs/box |
|
Sample |
1-3 work days |
|
Delivery |
3-4 work days |
|
Certificater |
ROHS |
|
Quality gurantee |
2 years warranty |
|
Main market |
Europe, America, Asia |
Applications:
- General lighting
- Outdoor & Indoor architectural lighting
- Decorative lighting
- Torch lighting
- Portable lighting and Reading lighting
- Traffic signaling
Competitive Advantage:
1. About 6 years specializing in High Power LED industry;
2. Complete supplying system with full range of Products,from high power leds ,led optical lens ,led constant drivers ,MCPCB modules and many led light components;
3. Strict process and quality control;
4. Good raw materials used in production.
5. Strong design with OEM Service and production capability.
