140lm/w 50W 90 Degree SMD3030 High Bay Light Module

140lm/w 50W 90 Degree SMD3030 High Bay Light Module
140lm/w 50W 90 Degree SMD3030 High Bay Light Module

Large Image :  140lm/w 50W 90 Degree SMD3030 High Bay Light Module

Product Details:
Place of Origin: Shenzhen,China
Brand Name: Sunshineopto
Certification: SGS,ROHS
Model Number: SUN-D252-84H1-90-TP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: 1pc/bag 0.18KG/SET
Delivery Time: 3-4 working days
Payment Terms: T/T,PAYPAL,Western Union,Money Gram
Supply Ability: 10000pcs/months
Detailed Product Description
Product Name: 50W 90 Degree High Bay Light Module With 3030SMD LED 1W 84 IN 1 With Heatsink 300x70x40mm Model No.: SUN-D252-84H1-90-TP
Beam Angle: 90 Degree LENS Size: 252x70x10.6mm
PCB Size: 239x45x1.5mm Circuit: 7 Series 12 Parallel
Output Voltage: 42V Output, 6V For Each Led Other Angle: 15/40/30x70/49x21/136x78 Degree , Vertical 136x78 Degree Lens
Heatsink: 300x70x40mm LED CHIP: PH 3030SMD LED 6V 1W White Color
High Light:

SMD3030 High Bay Light Module

,

140lm/w High Bay Light Module

,

50W Led Street Light Module

50W 90 degree High bay light module with 3030SMD LED 1W 84 IN 1 with heatsink 300x70x40mm

Quick Detail:


Model No.:SUN-D252-84H1-90-TP
Power 50-70W
Lumen value130-140lm/w
Beam angle90 degree
Other angle for choice15/40/60/30x70/49x21/136x78 degree , Vertical 136x78 degree lens
Circuit for board7 series 12 parallel ( can be customized)
Size252x70mm for lens, 239x45x1.5mm, 1.0w/m.k for board
Material for lensPC
LED CHIP1W Ph3030 smd 6v white color 3000-6500k
Heatsink300x70x40mm 50w Max.



Features :

  1. This SKD 84W LED Array lens with PCB Module is best design power lamps like 50-70w for per module.
  2. It’s the lowest total cost solution ,they can replace existing Metal Halide or HPS bulbs, the old housings can be re-used. The total cost is significantly reduced compared with using new complete LED fixtures.
  3. Industry-leading thermal management utilizing technology
  4. Operating temperature range: from 35 Celsius degree to 70 Celsius degree.
  5. The LED retrofit kits contain no any mercury or lead.


Applications:

It is used in the street light ,high way led lamp,tunnel lamp ,square lamp,road lamp, city lighting, parking spot lamp, track lighting fixtures ,scenery area ,retail lighting and other applications where high luminous flux is desired.


Specifications:


1, Product Name

50W 90 degree High bay light module with 3030SMD LED 1W 84 IN 1 with heatsink 300x70x40mm

2, Model No

SUN-D252-84H1-90-TP

3, Main parts

Array lens, silicon gasket, PCB board with LED+Heatsink

4, Lens Material

PC

5, Transmittance

93%

6, Sample

3-4 work day

7, Delivery

5-7 work days for 500 sets

8, Quality guarantee

If you receive defective items, please email us a picture of the defective part. We will send you replacement without extra charger, or offer refund.

9, Main market

Europe, South America,North America, Asia



Shipping and delivery time:


DHL/UPS/TNT/FEDEX

4-5 working days

EMS

10-15 working days

HK Post Air Mail Register

15-18 working days

Trade Terms

FOB|EXW|CIF|CNF

Sample availability

YES

Delivery time

3-4 working days



Competitive Advantage:

1). Using high quality for 3030SMD LED Series.
2). CE driver, very easy for repair/replacement
3). Higher lumen compared to similar models of others
4). Positive cooling technology
5). Reduce energy costs up to 90% compared to traditional lamps, reduce maintenance costs up to 90%, almost free of maintenance
6). Industry-leading thermal management utilizing technology
7). Top quality with warranty of 2 years warranty
8). LM80 testing reports available


90 Degree lens Dimensions and Beam Pattern:
140lm/w 50W 90 Degree SMD3030 High Bay Light Module 0
140lm/w 50W 90 Degree SMD3030 High Bay Light Module 1


140lm/w 50W 90 Degree SMD3030 High Bay Light Module 2

Test data for 84 led module:

140lm/w 50W 90 Degree SMD3030 High Bay Light Module 3
140lm/w 50W 90 Degree SMD3030 High Bay Light Module 4
