160lm/W 50w Led Street Light Module SMD 3030 PC Material

160lm/W 50w Led Street Light Module SMD 3030 PC Material

50w Led Street Light Module

160lm/W Led Street Light Module

PC Material Led Street Light Module

Place of Origin:

Shenzhen,China

Brand Name:

Sunshineopto

Certification:

SGS,ROHS

Model Number:

SUN-D252-84H1-136x78-TPII-S-V

Contact Us

Request A Quote
Product Details
Product Name:
50w Led Street Light Module , SMD 3030 LED Light Module 160lm/w For Led Street Light
Model No.:
SUN-D252-84H1-136x78-TPII-S-V
Angle:
136x78degree
Lens Dimension:
252x70x6.3mm
Lens Material:
Optical Grade PC
LED CHIP:
3030 SMD LED, 150-160lm/w 150mA,6v
Tranmittance:
91%
Accessory:
Gasket And Lens+PCB+ 3030SMD LED+Heat Sink
PCB Size:
226x57.9x1.5mm
PCB Circuit:
6 Series 14 Parallel
Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
Cartons
Delivery Time
3-4 working days
Payment Terms
T/T,PAYPAL,Western Union,Money Gram
Supply Ability
5000pcs/months
Product Description

50w Led Street Light Module , SMD 3030 LED Light Module 160lm/w For Led Street Light​

Product Feature:

1.We can according your require to design new Lens & Board.

2.This led street light module has a small size can match a variety of lamp housing .
3. Whole led light module use Ph3030 leds ,High quality leds guarantee long life .
4. This SKD 84 LED Array lens with PCB Module is best design power lamps like 50W for per module.

5. It’s the lowest total cost solution ,they can replace existing Metal Halide or HPS bulbs, the old housings can be re-used. The total cost is significantly reduced compared with using new complete LED fixtures.


Applications:

It is used in the street light ,high way led lamp,tunnel lamp ,square lamp,road lamp, city lighting, parking spot lamp, track lighting fixtures ,scenery area ,retail lighting and other applications where high luminous flux is desired.

Specifications:


1, Product Name

50w Led Street Light Module , SMD 3030 LED Light Module 160lm/w For Led Street Light

2, Model No

SUN-D252-84H1-136x78-TPII-S-V

3, Main parts

 Array lens , silicon gasket+PCB+LED+HEAT SINK

4, Lens Material

PC

5, Lens size

252X70x6.3MM

6, Transmittance

91%

7,LEDS

3030 SMD LED, 140-150lm 150mA,6v

8, Sample

3-4 work day

9, Delivery

5-7  work days for 10000 sets

10, Angle

136x78 degree

11, Quality guarantee

If you receive defective items, please email us a picture of the defective part. We will send you replacement without extra charger, or offer refund.

12, Main market

Europe, South America,North America, Asia








LENS Dimensions :

 160lm/W 50w Led Street Light Module SMD 3030 PC Material 0



Led Module test report :

160lm/W 50w Led Street Light Module SMD 3030 PC Material 1
