Bridgelux led chip high power 15W 1500lm , Pure White high power led modul

Bridgelux led chip high power 15W 1500lm , Pure White high power led modul

led chip high power

cob high power led

Place of Origin:

Shenzhen,China

Brand Name:

Sunshineopto

Certification:

LM-80,ROHS

Model Number:

SP15W

Contact Us

Request A Quote
Product Details
Led Holder Size:
29x20mm
Forward Voltage:
12-15V
Test Forward Current:
1050mA
CT:
2900-3200K , 4000-4500K , 4500-5000K,5000-5500K,5500-6000K,6000-6500K ,7000-9000K
Luminous Flux:
1350-1500lm
Led Circuit:
4 Series 4 Parallel
Payment & Shipping Terms
Minimum Order Quantity
100PCS
Price
Need to negotiate
Packaging Details
50PCS/REEL
Delivery Time
3-4 work days for 1000pcs.
Payment Terms
T/T,PAYPAL,Western Union,Money Gram
Supply Ability
10000 pcs for one week.
Product Description

Pure White High Power COB LED Bridgelux Chip 15W 1500lm For Floodlight


Quick Detail:


1.Model :SP15W
2.Led holder size :29x20mm
3.Forward Voltage :12-15V
4.Test Forward current : 1050mA
5.CT : 2900-3200K , 4000-4500K , 4500-5000K,5000-5500K,5500-6000K,6000-6500K ,7000-9000K
6.Luminous Flux : 1350-1500lm
7.RA >65
8.Reverse Voltage >18 Reverse
9.current(uA) <30 ESD Sensitivity (V) 3000
10.4 series 4 parallel

Usage: LED lighting , street light , flashlight , Floodlight etc.
Certificate: LM-80,ROHS




Description:

  1. Best raw materials used in our LED production :

    1)Chip: Bridgelux or Epistar  45MIL chip;
    2) Silicon glue: USA Dowcorning (good glue has less lighting decreasing);
    3) Powder: USA Intermatix (good powder has better performance in lumens);
    4) Gold wire: Germany Herqeus 1.0mil Gold wire(for bearing bigger current, gold wire has less electricity resistance than silver and cooper) ;
    5) Led base:red/ black cooper base .
    Super high Flux output and  high Luminance  ,Designed for high current operation,Low thermal resistance ,SMT solder technology ,Lead Free product,ROHS compliant
    We have many kind of color for your choice like : Warm white , Natural white , Cool white , Red , Blue , Green , Yellow etc.
    6) Accept small Order & 2 years warranty .


Specifications:


Product Name

15W 1500lm High Power COB LED Bridgelux Chip For Floodlight

Model No

SP15W

Finishing

COB Packing

Material

Epistar chip or Bridgelux chip 45mil

MOQ

100pcs

Size

29x20mm

Package

50pcs/reel ,100pcs /box

Sample

3-4 work days

Delivery

3-4 work days

Certificate

LM-80,ROHS

Quality gurantee

2 years warranty

Main market

Europe, America, Austria, Asia


The demensions of High power LED 15W as below :

Bridgelux led chip high power 15W 1500lm , Pure White high power led modul 0

Bridgelux led chip high power 15W 1500lm , Pure White high power led modul 1


Other Type of Holder For 15W  High Power LEDs :
Bridgelux led chip high power 15W 1500lm , Pure White high power led modul 2

Competitive Advantage of SUNSHINEOPTO :

1. About 6 years specializing in High Power LED industry;
2. Complete supplying system with full range of Products,from high power leds ,led optical lens ,led constant drivers ,MCPCB modules and many led light components;
3. Strict process and quality control;
4. Good raw materials used in production, using high quality USA Bridgelux chip .
5. Strong design with OEM service and production capability.

Applications:

General Illumination
- Outdoor & Indoor architectural lighting
- Decorative lighting
- Torch lighting
- Portable lighting and Reading lighting
- Traffic signaling
- Streetlight
