30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm

China 30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm supplier
30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm supplier 30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm supplier 30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm supplier

Large Image :  30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm

Product Details:

Place of Origin: Shenzhen,China
Brand Name: Sunshineopto
Certification: SGS, ROHS
Model Number: SP30WRGB

Payment & Shipping Terms:

Minimum Order Quantity: 50PCS
Price: Need to negotiate
Packaging Details: G.W.:180g
Delivery Time: 3-4 WORK DAYS
Payment Terms: T/T,PAYPAL,Western Union,Money Gram
Supply Ability: 10000pcs for one week
Contact Now
Detailed Product Description
Product Name:: 30W 45 Mil Full Color RGB High Power LED With R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm Size:: 56x40mm
Voltage:: R:20-25V,G:30-36V,B:30-36V Current:: R:400ma,G:350ma,B:350ma
Wavelength :: R:620-630nm,G:520-530nm,B:460-470nm Chips:: 45mil Chip
Luminous Flux:: R:400-500lm,G:600-700lm,B:100-200lm Thermal Resistance :: 12C/W



30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm



Quick Detail:


1. Model:SP30WRGB

2. Size: 56x40mm

2. Viewing angle: 90degree

3. Voltage:R:20-25V,G:30-36V,B:30-36V

4. Current:R:400ma,G:350ma,B:350ma

5. Wavelength : R:620-630nm,G:520-530nm,B:460-470nm

6. Chips: 45mil chip

7. Luminous Flux:R:400-500lm,G:600-700lm,B:100-200lm

8. Thermal Resistance :12C/W






Description:



Best raw materials used in our LED production :


1)Chip: Taiwan 45MIL chip;
2) Silicon glue: USA Dowcorning (good glue has less lighting decreasing);
3) Powder: USA Intermatix (good powder has better performance in lumens);
4) Gold wire: Germany Herqeus 1.0mil Gold wire(for bearing bigger current, gold wire has less electricity resistance than silver and cooper) ;
5) Led base:red/ black cooper base .
Super high Flux output and  high Luminance  ,Designed for high current operation,Low thermal resistance ,SMT solder technology ,Lead Free product,ROHS compliant
We have many kind of color for your choice like : Warm white , Natural white , Cool white , Red , Blue , Green , Yellow etc.
6) Accept small Order and 2 years warranty .



Specifications:


Product Name

30W RGB Power LED Chip , Full Color RGB LED Light

Model No

SP30WRGB

Finishing

Reflow soldering

 Material

 45mil Chip

MOQ

100pcs

Size

56x40mm

Package

10pcs/reel ,100pcs/box

Sample

1-3 work days

Delivery

3-4 work days

Certificater

SGS,ROHS

Quality gurantee

2 years warranty

 Main market

Europe, America, Asia


 30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm

30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm
30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm

30W 45 mil Full Color RGB High Power LED with R 620nm - 630nm , G 520nm - 530nm , B460nm - 470nm
Applications:

- General lighting
- Outdoor & Indoor architectural lighting
- Decorative lighting
- Torch lighting
- Portable lighting and Reading lighting
- Traffic signaling



Competitive Advantage:

1. About 6 years specializing in High Power LED industry;
2. Complete supplying system with full range of Products,from high power leds ,led optical lens ,led constant drivers ,MCPCB modules and many led light components;
3. Strict process and quality control;
4. Good raw materials used in production.
5. Strong design with OEM Service and production capability.
