3200K 120lm 1w High Power Led Bridgelux Chip Warm White 14.8*7.9mm Size

3200K 120lm 1w High Power Led Bridgelux Chip Warm White 14.8*7.9mm Size

1 watt high power led

high power 1w led

Place of Origin:

Shenzhen,China

Brand Name:

Sunshineopto

Certification:

LM-80,ROHS

Model Number:

SP1WWW120

Contact Us

Request A Quote
Product Details
Product Name::
120LM 1W High Power Led Bridgelux Chip WARM WHITE
Chips::
Bridgelux Chip
Luminous Flux::
110-120lm
Viewing Angle::
120degree,90 Degree , 60 Degree
Voltage::
3.0-3.6v
Current::
350ma
Color Temperature::
2900-3200k
Size::
14.8*7.9mm
Payment & Shipping Terms
Minimum Order Quantity
1000PCS
Price
Need to negotiate
Packaging Details
50PCS/REEL
Delivery Time
3-4 work days for 1000pcs.
Payment Terms
T/T,PAYPAL,Western Union,Money Gram
Supply Ability
100000 pcs for one week.
Product Description

120LM 1W High Power Led Bridgelux Chip WARM WHITE

Quick Detail:


1.Chips: Bridgelux chip

2.Luminous Flux:110-120lm

3.Viewing angle: 120degree,90 degree , 60 degree

4.Voltage:3.0-3.6v

5.Current:350ma

6.Color temperature: 2900-3200k

7.Size: 14.8*7.9mm

8.Model:SP1WWW120



Usage: LED lighting , street light , flashlight , LED bulb, Halogen lamp,Table light ,Light strips etc.

Certificate: LM-80,ROHS




Description:


  1. Best raw materials used in our LED production :

    1)Chip: Taiwan 45MIL chip;
    2) Silicon glue: USA Dowcorning (good glue has less lighting decreasing);
    3) Powder: USA Intermatix (good powder has better performance in lumens);
    4) Gold wire: Germany Herqeus 1.0mil Gold wire(for bearing bigger current, gold wire has less electricity resistance than silver and cooper) ;
    5) Led base:red/ black cooper base .
    Super high Flux output and  high Luminance  ,Designed for high current operation,Low thermal resistance ,SMT solder technology ,Lead Free product,ROHS compliant
    We have many kind of color for your choice like : Warm white , Natural white , Cool white , Red , Blue , Green , Yellow etc.
    6)Free samples and 2 years warranty .



Specifications:


Product Name

120LM 1W High Power Led Bridgelux Chip WARM WHITE

Model No

SP1WWW120

Finishing

Reflow soldering

Material

Epistar chip or Bridgelux chip 45mil

MOQ

1000pcs

Size

14.8*7.9mm

Package

50pcs/reel ,1000pcs/box

Sample

1-3 work days

Delivery

3-4 work days

Certificate

LM-80,ROHS

Quality gurantee

2 years warranty

Main market

Europe, America, Austria, Asia



3200K 120lm 1w High Power Led Bridgelux Chip Warm White 14.8*7.9mm Size 0



3200K 120lm 1w High Power Led Bridgelux Chip Warm White 14.8*7.9mm Size 1

Competitive Advantage of SUNSHINEOPTO :

1. About 6 years specializing in High Power LED industry;
2. Complete supplying system with full range of Products,from high power leds ,led optical lens ,led constant drivers ,MCPCB modules and many led light components;
3. Strict process and quality control;
4. Good raw materials used in production, using high quality USA Bridgelux chip .
5. Strong design with OEM service and production capability.



Applications:

General Illumination
- Outdoor & Indoor architectural lighting
- Decorative lighting
- Torch lighting
- Portable lighting and Reading lighting
- Traffic signaling
- Streetlight
