| Brand Name: | MEAN WELL |
| Model Number: | XLG-150-H-A |
| MOQ: | 10 |
| Price: | negotiate |
| Payment Terms: | T/T,PAYPAL,Western Union,Money Gram |
| Supply Ability: | 5000pcs/months |
| Model No. | XLG-150-H-A |
|---|---|
| Rated Current | 2.8A |
| Constant Current Region | 27-56V |
| Rated Power | 100VAC-305VAC / 150W |
| Current Adjustment Range | 1400-4170mA |
| Dimensions and Weight | 180×63×35.5mm, 0.8kg/set |
| Package | 16PCS/carton, weight 14KG |
XLG-150 series is a 150W LED AC/DC driver featuring the constant power mode.XLG-150 operates from 100~305VAC and offers modes with different rated current ranging between 700mA and 12500mA. Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for -40℃~+90℃ case temperature under free air convection .
The design of metal housing and Ip67 ingress protection level allows this series to fit both indoor and outdoor applications . Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world.
XLG-150 series comply with the latest version of IEC61347/GB19510.1 and UL8750 international safety regulations . The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the safety of both user and luminaire system during installation .
|
MODEL |
XLG-150-12-A |
XLG-150-24-A |
|
|
|
DC VOLTAGE |
12V |
24V |
|
|
CONSTANT CURRENT REGION Note.2 |
8.4~ 12V |
16.8~ 24V |
|
|
RATED CURRENT (Default) |
12.5A |
6.25A |
|
|
RATED POWER |
150W |
150W |
|
|
RIPPLE & NOISE (max.) Note.3 |
150mVp-p |
240mVp-p |
|
|
CURRENT ADJ. RANGE |
Adjustable for A-Type only (via the built-in potentiometer) |
|
|
6.5~ 12.5A |
3.2~ 6.25A |
||
|
OUTPUT |
VOLTAGE TOLERANCE Note.4 |
±3.0% |
±2.0% |
|
|
LINE REGULATION |
±0.5% |
±0.5% |
|
|
LOAD REGULATION |
±2% |
±1% |
|
|
SETUP, RISE TIME Note.6 |
500ms, 100ms/230VAC, 1200ms, 100ms/115VAC |
|
|
|
HOLD UP TIME (Typ.) |
10ms/ 230VAC 10ms/ 115VAC |
|
|
|
VOLTAGE RANGE Note.5 |
100 ~ 305VAC 142 ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" section) |
|
|
|
FREQUENCY RANGE |
47 ~ 63Hz |
|
|
|
POWER FACTOR |
PF≥0.97/115VAC, PF≥0.95/230VAC, PF≥0.92/277VAC@full load |
|
|
|
TOTAL HARMONIC DISTORTION |
THD< 10%(@load≥50%/115VC,230VAC; @load≥75%/277VAC) |
|
|
INPUT |
EFFICIENCY (Typ.) |
91.5% |
93% |
|
|
AC CURRENT |
1.8A / 115VAC 1.0A / 230VAC 0.8A/277VAC |
|
|
|
INRUSH CURRENT(Typ.) |
COLD START 50A(twidth=500μs measured at 50% Ipeak) at 230VAC; Per NEMA 410 |
|
|
|
MAX. No. of PSUs on 16A CIRCUIT BREAKER |
4 units (circuit breaker of type B) / 8 units (circuit breaker of type C) at 230VAC |
|
|
|
LEAKAGE CURRENT |
<0.75mA / 277VAC |
|
|
|
NO LOAD POWER CONSUMPTION |
No load power consumption <0.5W(for standard version) |
|
|
MODEL |
XLG-150-L-A |
XLG-150-M-A |
XLG-150 -H-A |
|||
|
|
RATED CURRENT (Default) |
700mA |
1400mA |
2800mA |
||
|
|
RATED POWER |
150W |
150W |
150W |
||
|
|
CONSTANT CURRENT REGION |
120 ~214V |
60 ~ 107V |
27 ~ 56V |
||
|
|
FULL POWER CURRENT RANGE |
700~1050mA |
1400~2100mA |
2680~4170mA |
||
|
OUTPUT |
OPEN CIRCUIT VOLTAGE (max.) |
225V |
115V |
60V |
||
|
|
CURRENT ADJ. RANGE |
Adjustable for A/AB-Type only (via the built-in potentiometer) |
||||
|
350~1050mA |
700~2100mA |
1400~4170mA |
||||
|
|
CURRENT RIPPLE |
4.0%(@ full load) |
3.0%(@ full load) |
3.0%(@ full load) |
||
|
|
CURRENT TOLERANCE |
±5% |
||||
|
|
SET UP TIME |
500ms/230VAC, 1200ms/115VAC |
||||
|
|
VOLTAGE RANGE Note.5 |
100 ~ 305VAC 142VDC ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" ang “ DRIVING METHODS OF LED MODULE"section) |
||||
|
|
FREQUENCY RANGE |
47 ~ 63Hz |
||||
|
|
POWER FACTOR (Typ.) |
PF≥0.97 / 115VAC, PF≥0.95 / 230VAC , PF≥0.92 / 277VAC at full load (Please refer to "Power Factor Characteristic" section) |
||||
|
|
TOTAL HARMONIC DISTORTION |
THD< 10% (@ load≥50% at 115VAC/230VAC ,@load≥75% at 277VAC) Please refer to “TOTAL HARMONIC DISTORTION (THD)” section |
||||
|
|
EFFICIENCY (Typ.) |
93% |
92.5% |
92% |
||
|
INPUT |
AC CURRENT (Typ.) |
1.8A / 115VAC 1.0A / 230VAC 0.8A/277VAC |
||||
|
|
INRUSH CURRENT(Typ.) |
COLD START50A(twidth=500μs measured at 50% Ipeak) at 230VAC; Per NEMA 410 |
||||
|
|
MAX. NO. of PSUs on 16A CIRCUIT BREAKER |
4 unit(circuit breaker of type B) / 8 units(circuit breaker of type C) at 230VAC |
||||
|
|
LEAKAGE CURRENT |
<0.75mA / 277VAC |
||||
|
|
STANDBY POWER CONSUMPTION Note.14 |
Standby power consumption <0.5W for AB-Type(Dimming OFF)(for standard version) |
||||
|
DHL/UPS/TNT/FEDEX |
4-5 working days |
|
EMS |
10-15 working days |
|
HK Post Air Mail Register |
15-18 working days |
|
Trade Terms |
FOB | EXW | CIF | CNF |
|
Sample Availability |
YES |
|
Standard Delivery Time |
3-4 working days |
