120-135W LED Power Supply with Adjustable DC Output Voltage and DIN Rail Mountable

Brand Name:	MEAN WELL
Model Number:	HDR-150-12
MOQ:	10
Price:	Negotiate
Packaging Details:	Cartons
Payment Terms:	T/T,PAYPAL,Western Union,Money Gram

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

Shenzhen,China

Certification:

SGS,RoHS,CE

Document:

Power:

120-135W

Output Voltage:

Output Current:

10.2A/11.3A

Input Voltage:

85-264VAC/120-370VAC

Input Efficiency:

Warranty:

3 Years

Supply Ability:

10000pcs/months

Highlight:

120-135W LED Driver

Adjustable DC Output Voltage DIN Rail Power Supply

DIN Rail Mountable Constant Current LED Power Supply

Product Description

120-135W LED Power Supply with Adjustable DC Output Voltage and DIN Rail Mountable

Key Features

Ultra slim design with 105mm (6SU) width
Universal input 85-264VAC (277VAC operational)
No load power consumption <0.3W
Isolation class II
DC output voltage adjustable
Protections: Short circuit / overload / over voltage
Cooling by free air convection
DIN rail TS-35/7.5 or 15 mountable
Over voltage category III
LED indicator for power on

Product Description

The HDR-150-12 is an economical ultra slim 150W DIN rail power supply, designed for installation on TS-35/7.5 or TS-35/15 mounting rails. Featuring a plastic housing that effectively prevents electrical hazards, this power supply achieves up to 89% working efficiency and operates in ambient temperatures from -30℃ to 70℃ with air convection. Complete protection functions and relevant certifications (IEC62368-1, UL62368-1, UL61010, BS EN/EN61558-2-16) make the HDR-150 a competitive power solution for household and industrial applications.

Technical Specifications

Model No.	HDR-150-12
Power	120-135W
Input Voltage	85-264VAC/120-370VAC
Input Efficiency	89%
Output Voltage	12V
Output Current	10.2A/11.3A
Warranty	3 years
Dimensions	105x90x54.5mm
Packing	0.31kg, 32pcs/11kg/1.0CUFT

MODEL		HDR-150-12	HDR-150-15	HDR-150-24	HDR-150-48
OUTPUT	DC VOLTAGE	12V	15V	24V	48V
	RATED CURRENT	115VAC: 10.2A 230VAC: 11.3A	115VAC: 8.55A 230VAC: 9.5A	115VAC: 5.31A 230VAC: 6.25A	115VAC: 2.72A 230VAC: 3.2A
	RATED POWER	115VAC: 122.4W 230VAC: 135.6W	115VAC: 128.3W 230VAC: 142.5W	115VAC: 127.4W 230VAC: 150W	115VAC: 130.6W 230VAC: 153.6W
	RIPPLE & NOISE (max.)	100mVp-p	120mVp-p	150mVp-p	200mVp-p
	VOLTAGE ADJ. RANGE	10.8 ~ 13.8V	13.5 ~ 18V	21.6 ~ 29V	43.2 ~ 55.2V
	VOLTAGE TOLERANCE	±2.0%	±1.0%	±1.0%	±1.0%
	LINE REGULATION	±1.0%	±1.0%	±1.0%	±1.0%
	LOAD REGULATION	±1.0%	±1.0%	±1.0%	±1.0%
	SETUP, RISE TIME	500ms, 60ms/230VAC 500ms, 60ms/115VAC at full load
	HOLD UP TIME (Typ.)	30ms/230VAC 12ms/115VAC at full load
INPUT	VOLTAGE RANGE	85 ~ 264VAC (277VAC operational) 120 ~ 370VDC (390VDC operational)
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	89%	89.50%	90.50%	90.50%
	AC CURRENT (Typ.)	3A/115VAC 1.6A/230VAC
	INRUSH CURRENT	COLD START 35A/115VAC 70A/230VAC

Product Details

Shipping & Delivery Informations

DHL/UPS/TNT/FEDEX	4-5 working days
EMS	10-15 working days
HK Post Air Mail Register	15-18 working days
Trade Terms	FOB\|EXW\|CIF\|CNF
Sample Availability	YES
Standard Delivery Time	3-4 working days

Applications

Street lighting systems
Highway LED lamps
Tunnel lighting
Square and area lighting
Road and parking spot lamps
Track lighting fixtures
Landscape and scenery area lighting
Retail and commercial lighting
High luminous flux applications

For any requests or questions, please feel free to contact us.
