15W LED power supply , 12V LED Constant Voltage Driver for LED Strips,Decorative Lighting
Quick Detail:
Description:
1 Environmental Conditions
1.1 Operating Temperature: -10℃~+50℃, 20%~95%RH(without condensation)
1.2 Storage Temperature: -20℃~+85℃, 20%~95%RH(without condensation)
1.3 Relative Humidity: 0.02~0.05%/℃
1.4 Heat-dissipating Method: Natural Cooling / Fan Cooling / Blower Cooling
2. Input Features
2.1 Rated Input Voltage Range:220VAC
2.2 Input Voltage Range: 110/220VAC±15%
2.3 Input Frequency Range:50~60Hz(except Dc input)
2.4 Input Under-voltage Protection:115~150% interim mode
2.5 Input Under-voltage Recovery: Automatic recovery
2.6 Input Over-voltage Protection:115~150% interim mode
2.7 Input Over-voltage Recovery: Automatic recovery
2.8 Impact Current ≤1% (the highest input voltage full load)
2.9 Overall Efficiency ≤0.5% (rated input full load)
3. Output Features
3.1 Output Voltage Range: 12V±2%(Dual Outputs)
3.2 Output Current Range: 8.33A±0.5%(Dual Outputs)
3.3 Ripple & Noise(mVp-p)≤200 mVp-p
3.4 Rise Time≤50 ms/230V AC
3.5 Output Delay≤S
3.6 Voltage Adjustment Rate≤0.5%
3.7 Load Adjustment Rate≤1%
Specifications:
Product Name |
LED Street Light power supply , 100W LED Constant Voltage Driver for LED Tunnel Lamp |
Model No |
S-100W-12V |
Material |
Aluminum case |
Sample |
3-5 work days |
Delivery |
7-10 work days |
Certificate |
ROHS |
Quality guarantee |
2 years warranty |
Main market |
Europe, America, Asia |
Shipping and delivery time:
DHL/UPS/TNT/FEDEX |
4-5 working days |
EMS |
10-15 working days |
HK Post Air Mail Register |
15-18 working days |
Trade Terms |
FOB|EXW|CIF|CFR |
Sample availability |
YES |
Delivery time |
7-10working days |
Competitive Advantage:
1 . Output Over Current Protection: Current drooping type
2. Output Short Circuit Protection: IGBT
3. Output Over-voltage Protection: Soft start protection
4. Reliability Requirements
5. MTBF:50,000 HOURS
6. Annual Repair Rate<0.3%
Applications:
General Illumination
- Outdoor & Indoor architectural lighting
- Decorative lighting ,led strips
- Flood lighting,cast light lamps
- Street lamp,Tunnel lamp
- Replace the old equipment
